What is ARINC 429?
ARINC 429 is a 2-wire databus standard used primarily for commercial, private, and some military aircraft.
ARINC 429 integrated circuit is an Air Transport Industry standard for the transfer of digital data between avionics systems. This standard defines the Electrical Interface, Label and Address assignments, and Word Format Description. Check out the Applications section below to learn how ARINC 429 Interface, IC Data Bus, and Integrated Circuits can be applied to a wide variety of applications. If you have a question about our ARINC 429 products or ARINC 429 for Commercial Avionics, contact us today.
Based on the ARINC 429 specification for serial communication, Device Engineering has developed a complete product line of Line Drivers that convert TTL or CMOS signals to differential RZ data…
The ARINC 429 Line Receiver converts ARINC 429 differential RZ data to TTL/CMOS compatible outputs.
Waveform of ARINC 429 Signals
The Waveform of the ARINC 429 signals follows a differential bipolar RZ type. As shown in the diagram, logic levels are determined by the voltage difference between the two communication lines. There are many timing and voltage level specifications associated with the ARINC 429 specification. This data can be found primarily in the ARINC 429 specification itself, however, DEI has included the most pertinent information within the data sheets of our interface devices. For more information on ARINC 429 Interface, IC Data Bus & Integrated Circuits, contact us today.
